GARAGES AND BUILDINGS

Please browse through our catalogue of example structures. If you do not see an example of what you require please contact us – our product is very flexible and adaptable.

Click on any picture to see a larger version (when the large picture is displayed if you move your mouse over the left or right of the picture you will be able to select the previous/next picture).





The unique  S.I.S. steel framing system means your building can be quickly  constructed saving time on site and labour costs. Our buildings range from , double garages workshops, storage buildings and warehouses with spans up to 16 meters.

Plus all our buildings are EXPANDABLE so you can make it larger as circumstances permit.



Steel Interlock Sheds frame and sheet metal summary:

·  75×50 ml – 14 Gage Galvanized Tube. Interior Tube Painting to prevent rusting from inside.

·  FLO-COAT Finish: Process of 3 lacquers applied to tube allowing twice the salt spray life and rust protection.

·  Swaged Connections: Patented End Reduction Design allowing tubing to slip-fit together.

·  Smooth Mandrel Bends (Stronger than typical compression bend offered by other brands).

·  40 ml sq. Flush Mount End Wall Girts – 18 gauge – Galvanized.

·  Tophat 40 Hat Channel side wall and roof purlins, 900 on center spacing. 14 degree roof pitch

·  .40 Zincalume or Colorsteel, Manufacturers warranty

·  TrimRib Panel profile, Ridge Cap, Eave Trim, Gable Trim, Corner Trim, J-Channel Door Trim.



Our garages and buildings come in a wide variety of widths, lengths and heights, so for a free quote please call us on 0800 777 717 or contact us.
